Orange Silica Gel

型號(hào)orange silica gel

Its main component is silicon dioxide and its color varies with the humidity. With the exception of blue silica gel’s performance, it also has characters of cobalt chloride free, non-toxic, odorless, harmless, etc.Its molecular formula is: SiO2 + H2O + C25H30CLN3

Detailed information

Orange Silica Gel Indicator

   COMPOSITION
   Its main component is silicon dioxide and its color varies with the humidity. With the exception of blue silica gel’s performance, it also has characters of cobalt chloride free, non-toxic, odorless, harmless, etc.
Its molecular formula is: SiO₂ + H₂O + C₂₅H₃0CLN₃
   PERFORMANCE AND USAGE
   In 1998, the European Union has identified the cobalt chloride as carcinogens in the second category. Blue silica gel with cobalt chloride in Europe and theUnited Stateshas been banning to produce, and it has a tendency to be eliminated gradually. In order to adapt to market’s needs, our company developed orange silica gel without cobalt chloride.
   The product can be used alone or be mixed with other silica gel.To dry and indicate the humidity, we can place appropriate amount of the goods in appropriate containers or packaging to achieve this purpose.
   This product is mainly used for drying, instructing the degree of drying or humidity, and widely used in precision instruments, pharmaceuticals, petrochemicals, food, clothing, leather, home appliances and other industrial gases, etc. It can also be used for domestic purposes such as moisture proofing and dehumidifying.
   Orange silica gel has a strong capacity of absorption moisture. During the process of absorption moisture, the appearance of the color changes obviously according to the hygroscopic capacity. So it’s often called "humidity indicator."
   PHYSICAL CHARACTERISTICS

ITEM	ORANGE SILICA GEL
Bulk Density（g/ml）	0.75
Speciic Surace Area（m²/g）	700
Average Pore Diameter（nm）	2.4
Pore Volume（ml/g）	0.32-0.39
Speciic Heat（KJ/kg.℃）	0.92
Thermal Conductivity (KJ/m.Hr.℃）	0.63
Regeneration Temperature（℃）	100~120

【TECHNICAL SPECIFICATION】

ITEM			SPECIFICATION			Typical Value
ITEM			Superior Class	First Class	Qualified Class	Typical Value
Adsorptionc Capacity	RH=20%,% ≥		12	10	8	9
	RH=35%,% ≥		20	18	15	17
	RH=50%,% ≥		27	24	20	25
	RH=90%,% ≥		40	36	30	35
Rattler Loss,%≤			10	10	10	10
PH Value			2-4	2-4	2-4	4.0
Specific Resistance ,Ω.cm ≥			5000	3500	3000	3500
Silica ,% ≥			98.2	98	98	98
Qualified Ratio of Spherical Granules ,% ≥			95	90	80	85
Ratio of Size Qualified ,% ≥			100	99.5	90	97
Moisture Content,% ≥			1.5	2.0	5.0	5.0
Bulk Density, g/ml			0.78	0.75	0.70	0.76
Color		RH 20% ≥	Light Yellow
		RH 35% ≥	Light Green
		RH 50% ≥	Light Dark Green
Original Color			Orange
Notes: The value of qualified ratio of spherical granules is just applicable to the qualified ratio of silica gel spherical granule.

   PRODUCT SPECIFICATION:1-3mm, 2-4mm, 2-5mm, 3-5mm, 4-8mm
   PACKAGING MATERIAL:25KG/bag,500KG/bag, Plastic bag, Compound bag, One Ton/bag.
   PACKAGING AND STORAGE:
  Orangesilica gel has a strong capacity of absorption moisture. Therefore it should be stored in a dry place, with shelves or pallets between the ground and the goods. Packaging Material has steel drum, paper can, carton, plastic bottle, polyethylene plastic compound bag, flexible container bags, etc. During transportation, it should keep away from the rain, the damp and exposure.
